G-M/Opel 재설정 도구용 타이어 압력 모니터 센서 EL 50448 TPMS

Descriptions:

Most of For G.M vehicles equipped with a 315 or 433 MHz (TPMS) Tire Pressure Monitoring system, a "Sensor Re-Learn Procedure" must be performed after tire rotations, Remote Control Door Lock Receiver Module replacement or Tire Pressure Sensor replacement. This re-learn procedure can be performed by using EL-50448 special tire pressure tool. EL-50448 works on 2014 For G.M models too.

Introduction :

1.The tire pressure sensor on models in & after 2012 can be read, only with some specified diagnostic tools.

2.Before tire pressure monitoring system works normally properly, the body control module will record ID information of each position in the tire pressure sensor.

3.Please refer to the specific methods as follows:

Step 1 - Enter leaning mode

-Set the gearshift lever to "P"

-Put the ignition switch to "ON"

-Enter the interface of tire pressure display by DIC

-DIC shows "Press Set / Ctrl to re-learn"

-Press "Set / Ctrl"

-The turn signal is lighted for 3 seconds and the horn beep sound twice to enter the learning mode

Step 2 - Read tire pressure sensor information

-Start from the front-left wheel,

-Make the J-46079 or Diagnostic Tool EL-50448 antenna up against the valve core position & close to the rim of the -tire sidewall

-El-50448 tire pressure tool starts by the start switch

-Successful to read the tire pressure sensor information when the horn bleeps once

Step 3 - Same method to read other tire pressure information

Follow the instuction above to read tire pussure of the front-right, rear-right, rear-left wheels.

Turn signals is lighted for 3 seconds and the horn bleeps twice when the learning is complete.

Please Note :

For certain vehicles equipped with a Tire Pressure Monitoring (TPM) system, a "Sensor Re-Learn Procedure" must be performed after tire rotations, Remote Control Door Lock Receiver Module replacement or Tire Pressure Sensor replacement. This re-learn procedure can be performed by using special tool 50448

Car List:

2001 For DeVille(VIN K) Service Manual

2001 For Seville(VIN K) Service Manual

2002 For Corvette (VIN Y) Service Manual

2002 For DeVille(VIN K) Service Manual

2002 For Seville, For Seville RHD(VIN K) Service Manual

2003 For Corvette (VIN Y) Service Manual

2003 For DeVille (VIN K) Service Manual

2003 For Seville (VIN K) Service Manual

2004 For Avalanche/Escalade/Suburban/Tahoe/Yukon(VIN C/K) Service Manual

2004 For SRX (VIN E) Service Manual

2004 For XLR (VIN Y) Service Manual

2005 For Avalanche/Escalade/Suburban/Tahoe/Yukon(VIN C/K) Service Manual

2005 For Corvette (VIN Y) Service Manual

2005 For CTS (VIN D) Service Manual

2005 For DeVille (VIN K) Service Manual

2006 For 9-7x (VIN S/T) Service Manual

2006 For Avalanche/Escalade/Suburban/Tahoe/Yukon(VIN C/K) Service Manual

2006 For Corvette (VIN Y) Service Manual

2006 For CTS (VIN D) Service Manual

2006 For Impala/Monte Carlo (VIN W) Service Manual

2007 For 9-7x (VIN S/T) Service Manual

2007 For Envoy/Rainier/TrailBlazer/Ascender (VIN S/T) Service Manual

2007 For Equinox/Torrent (VIN L) Service Manual

2007 For Grand Prix (VIN W) Service Manual

2007 For H3 (VIN N) Service Manual

And So on.......

Parcking List :

1 x EL50448

Notice:The package does not include the charger and battery.
