240/296/352/708pcs HID 방수 커넥터 1/2/3/4 핀 자동차 전기 Electri 와이어 커넥터 플러그 트럭 하네스

708pcs Specification:

Quantity:708pcs
Wholesale : Support
Contact material: copper
Shape: stripes
Working frequency: low frequency
Features: Waterproof
Number of cores: 1-6
Number of pins: 1-6
Product Weight:700g(Approx.)
Storage Box size :27.50 x 18.00 x 5.00
Waterproof connection parameters:
1 hole male rubber cup DJ7011-1.5-11 (black) (10 pieces)
1 hole red clip DJ7011-1.5-11 (red) (10 pieces)
2-hole outer rubber bowl DJ7021-1.5-11 (black) (8 pieces)
2-hole red clip DJ7021-1.5-11 (red) (8 pieces)
3-hole outer rubber shell DJ7031-1.5-11 (black) (8 pieces)
3-hole red clip DJ7031-1.5-11 (red) (8 pieces)
4-hole outer rubber bowl DJ7041-1.5-11 (black) (6 pieces)
4-hole red clip DJ7041-1.5-11 (red) (6 pieces)
5 holes male plastic shell DJ7051-1.5-11 (black) (6 pieces)
5 hole red clip DJ7051-1.5-11 (red) (6 pieces)
6-hole outer rubber bowl DJ7061-1.5-11 (black) (5 pieces)
6 hole red clip DJ7061-1.5-11 (red) (5 pieces)
1 hole Masterbatch Shell DJ7011-1.5-21 (black with yellow) (10 pieces)
1 hole red clip DJ7011-1.5-21 (red) (10 pieces)
2-hole masterbatch shell DJ7021-1.5-21 (black with yellow) (8 pieces)
2-hole red clip DJ7021-1.5-21 (red) (8 pieces)
3-Hole Masterbatch Shell DJ7031-1.5-21 (black with yellow) (8 pieces)
3-hole red clip DJ7031-1.5-21 (red) (8 pieces)
4-Hole Masterbatch Shell DJ7041-1.5-21 (black with yellow) (6 pieces)
4-hole red clip DJ7041-1.5-21 (red) (6 pieces)
5-Hole Masterbatch Shell DJ7051-1.5-21 (black with yellow) (6 pieces)
5-hole red clip DJ7051-1.5-21 (red) (6 pieces)
6-Hole Masterbatch Shell DJ7061-1.5-21 (black with yellow) (5 pieces)
6 hole red clip DJ7061-1.5-21 (red) (5 pieces)
Bare-End-DJ611-1.5 (Copper-Nickel Plating) (134 pieces)
Female Bare End DJ621-1.5 (Copper-Nickel Plating) (134 pieces)
Waterproof rubber stopper (yellow) (268 pieces)

296pcs Specification :

Quantity:296pcs
Wholesale : Support
Voltage: max. 24 volts
Color (housing): black
Temperature: -40 ° C - + 125 ° C
Cross-sectional area: 0.35mm² - 2.50mm²
Cable diameter: 1.20mm - 3.30mm
Product Weight:300g(Approx.)
Storage Box size :20.00 x 13.80 x 3.80(Approx.)
Current: max. 14A at 1.50mm² (with correct crimp connection)
Housing material: PA 6 (glass fiber reinforced)
Leak tightness: IP67 according to IEC 60529 and DIN 40050-9 (with correct crimp connection)
Media resistance: ozone, salts, gasoline, diesel, brake fluid and engine oil
Accessories Details Are As Follows :
1-pin set waterproof plug connector:
2 x one pin male connector and insert
2 x One Pin Female Connector Housing and Insert
2 x male terminals
2 x female terminal

2-pin set waterproof plug connector:
3 x two pin male connector housing and insert
3 x Two Pin Female Connector Housing and Insert
3 x male terminals
3 x female terminal

3-pin set of waterproof plugs:
3 x three pin male connector housing and insert
3 x Three Pin Female Connector Housing and Insert
3 x male terminals
3 x female terminal

4-pin set of waterproof plugs:
2 x four prong male connector and insert
2 x four pin female connector housing and insert
2 x male terminals
2 x female terminal

5-pin set of waterproof plug connectors:
2 x five prong male connector and insert
2 x Five Pins Female Connector Housing and Insert
2 x male terminals
2 x female terminal

6-pin set of waterproof connectors:
2 x six prong male connector and insert
2 x Six Pin Female Connector Housing and Insert
2 x male terminals
2 x female terminal
Seal green: 20 pieces (cable diameter 1.20mm - 1.60mm)
Seal yellow: 80 pieces (cable diameter 1.70mm - 2.40mm)
Seal red: 20 pieces (cable diameter 2.50mm - 3.30mm)
40 pieces socket + 40 pieces pin contacts 1.50mm²-2.50mm²
1 piece (removable spacer, dimensions 200x138x38mm)
