HTB-GS-03 기가비트 광섬유 미디어 컨버터 10/100/1000Mbps 단일 모드-RJ45 3KM/20KM UPC/APC SC-포트 미국 전원 공급 장치

Type: Fiber Optic Converter

Model: HTB-GS-03

Transmission Distance: Single-mode up to 3km or 20km

Fiber Optic Connector: SC/APC, SC/UPC

Ethernet Connector: RJ45

Ethernet Rate: 10/100/1000Mbps

Fiber Port Speed: 1.25G

Wavelength: A-Side TX 1310nm / RX 1550nm, B-Side TX 1550nm / RX 1310nm

Instruction

The Gigabit Ethernet Media Converters with an external power supply is designed to transmit and receive 10/100/1000Mbps data over optical fiber.

The electrical interface will Auto-Negotiate to a 100Mbps or 1000Mbps Ethernet rate without any adjustments.

The optical interface operates at a 1000Mbps Ethernet rate.

Both are environmentally hardened to operate in extreme temperatures.

LED indicators are provided for confirming equipment operating status.

Feature

One 1.25Gbps full-duplex fiber port and one 1000M Ethernet port.

Each port has the complete LED Indicator light for installation, commissioning, and maintenance.

Support 9K Jumbo Packet.

Support direct forwarding mode, which supports less time delay.

Low power consumption, only 1.5W in full load condition.

Support isolation protection function, and good data security.

Small size, suitable for installation in various places.

Auto-negotiation low power consumption chips to ensure very longtime and stable operation.

100% Brand New and High Quality.

Shape & Color: Same as the picture show

The Type As Your Choice!!

The Quantity As Your Choice!!

Thanks for your visit & Happy cooperation!!

Note: Due to nature and measurement tools, coupled with the purely manual measurement and cutting of the cable, it may cause a length error of 1%-5%.
